Product Description
Autel MaxiDiag MD600CV: Commercial Vehicle Diagnostics for Class 3–9 Trucks and Buses
The Autel MaxiDiag MD600CV is a wireless Android touchscreen tablet built specifically for heavy-duty commercial vehicle diagnostics. If you are a fleet technician, shop owner, or owner-operator working on Class 3 through Class 9 trucks and buses, this is Autel's purpose-built solution for quick systems triage, maintenance tasks, and advanced fault diagnosis without dragging out a laptop.
At its core, the MD600CV is a 5.5-inch handheld that pairs wirelessly with the included MaxiVCI V200 — a multi-protocol Bluetooth VCI that speaks the commercial vehicle languages your trucks actually use: J1708, J1939, J1587, J1850, CDL, PLC, and VPW. The Deutsch 6-pin and 9-pin connectors are in the box. You are ready to plug into most commercial vehicles on day one.
Who This Tool Is For
The MD600CV hits a practical sweet spot for two types of users:
- Fleet service managers and technicians who need thorough all-systems access across a mixed heavy-duty fleet — trucks, buses, Class 3 through Class 9 — without the cost or complexity of a full MaxiSYS workstation.
- Owner-operators and small shops doing their own maintenance who need reliable DPF regen, oil resets, injector coding, and brake bleed on their own equipment.
This is not a light-duty crossover tool wearing a commercial badge. It is dedicated HD coverage with Expert Mode access to engine, exhaust, gearbox, ABS, EBS, SUS, and BCM systems — the systems that matter on working trucks.
Diagnostic Capabilities
- Read and Erase DTCs across all supported systems
- View Live Data — stream and monitor real-time sensor and parameter data
- Bi-Directional Active Tests — command components to verify operation
- AutoScan — automatically scan all available systems on the connected vehicle
- Expert Mode — direct access to OE-specific components including engine, transmission, and braking systems
- Trailer ABS diagnostics (requires the Trailer PLC connector, sold separately)
Service and Maintenance Functions
The MD600CV handles the service tasks that keep heavy-duty equipment running between major repairs:
- DPF Regeneration — Autel claims industry-leading DPF regen coverage on commercial vehicles. This alone is worth serious consideration for diesel-heavy fleets.
- Oil Light Reset
- Injector Coding and Reset
- Brake Bleed
These are the recurring maintenance operations that shops perform on trucks week after week. Having them in a wireless handheld means the tech can work at the vehicle without being tethered to a cart or laptop.
Wireless VCI: MaxiVCI V200
The included MaxiVCI V200 is the communication bridge between the tablet and the vehicle. It handles the full range of commercial vehicle protocols:
- J1939 (the backbone of modern HD diagnostics)
- J1708 and J1587 (older heavy-duty networks still common in pre-2007 trucks)
- J1850 VPW and PWM
- CDL, PLC, VPW
- Standard OBD-II protocols: ISO9141-2, ISO14230-2, ISO15765, K/L-Line, all CAN variants including fault-tolerant CAN, CAN FD, SAE J2610, GM UART, Honda Diag-H, TP2.0, TP1.6, ISO 13400
Hardware Specifications
| Operating System | Android 9.0 |
| Processor | Quad-core, 1.5 GHz |
| RAM / Storage | 2 GB RAM / 64 GB ROM |
| Display | 5.5-inch LCD capacitive touchscreen, 1280 x 720 |
| Camera | 8 MP rear |
| Connectivity | Wi-Fi 802.11 a/b/g/n/ac, Bluetooth, USB Type-C |
| Battery | 3.8 V / 5000 mAh lithium-polymer |
| Charging | 5 V / 2 A adapter |
| Operating Temperature | 0 to 50 C (32 to 122 F) |
| Dimensions | 89 x 183 x 22 mm (3.5" x 7.2" x 0.87") |
| Weight | 368 g (0.8 lb.) |
What Is Included
- MD600CV diagnostic tablet
- Wireless MaxiVCI V200 with J1708, J1939, J1587, J1850, CDL, PLC, VPW support
- Deutsch 6-pin connector
- Deutsch 9-pin connector
- One year free software updates
- One-year limited warranty
Note: Trailer PLC connector for trailer ABS diagnostics is sold separately.
MD600CV vs. Stepping Up to the MS909CV
If the MD600CV covers your workflow, it is a solid, focused tool. If your shop needs OEM-level programming, J2534 pass-thru capability, or works on construction and agricultural equipment alongside trucks, Autel's MS909CV adds a 9.7-inch screen, MFVCI with J2534/RP1210 support, network module topology mapping, and battery/starting/charging analysis. For pure triage and maintenance on a Class 3-9 fleet, the MD600CV gets it done at a lower investment.
